Nominal Diameter |
18”/ 460 mm |
|
Voice Coil Diameter |
4.5” / 114.15 mm |
|
Nominal Impedances |
8 Ohms |
|
Rating Power |
1800 W (A.E.S) |
|
Program Power |
3600 W |
|
Sensitivity (1w - 1m) |
98dB |
|
Frequency Range |
40Hz - 2kHz |
|
Magnet Dimensions (OD x ID) |
245 x 29 (mm) |
|
Chassis Material |
Aluminium |
|
Magnet Material |
Ferrite |
|
Voice Coil Material |
Copper |
|
Former Material |
GBF |
|
Dust Dome Material |
Paper |
|
Cone / Surround Material |
Paper /Colth |
|
Magnet Gap heigh |
15 mm / 0.59" |
|
Voice Coil Winding height |
28 mm / 1.1" |
|
Recommended Enclosure Volume |
200 litres |
|
Connector Type |
Push Button Spring Terminals |
|
Re |
5.7Ω |
|
Fs |
39 Hz |
|
Mms |
166g |
|
Cms |
0.1 mm/N |
|
Qms |
9.499 |
|
Qes |
0.306 |
|
Qts |
0.296 |
|
Vas |
200 litres |
|
Le |
1.0 mH |
|
Sd |
1.195K cm² |
|
BxL |
27.6 |
|
Xmax |
10.25 mm / 0.4" |
|
Xmech (Ref. Efciency) |
3.842 % |
|
Overall Diameter |
460mm |
|
Bolt Circle Diameter |
443mm |
|
Mount Buffer Cut-out |
422mm |
|
Depth |
238mm |
|
Net Weight |
15.8 kg |
