Nominal Diameter |
18inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
4ohm |
|
Nominal Power Handling |
1000Watts |
|
Continuous Power Handling |
2000Watts |
|
Sensitivity |
96.2dB |
|
Frequency Range |
41-2KHz |
|
Voice-coil Diameter |
99.5mm |
|
Voice-coil Material |
EISV |
|
Kind of layer |
In/out |
|
Magnet Diameter |
220mm |
|
Magnet Material |
Ferrite |
|
Resonance Frequency |
Fs |
41Hz |
|
DC Resistance |
Rte |
4ohm |
|
Mechanical Factor |
Qms |
7.851 |
|
Electrical Factor |
Qes |
0.456 |
|
Total Factor |
Qts |
0.431 |
|
BL Factor |
BL |
21.112T-m |
|
Effective Moving Mass |
Mms |
193.85gr |
|
Equivalent Cas Air Load |
Vas |
167.1liter |
|
Effective Piston Area |
Sd |
0.12 m |
|
Max. Linear Excursion |
Xmax |
10mm |
|
Vibration velocity |
Cms |
0.075 |
|
Overall Diameter |
461mm |
|
Baffle Cut-out Dia. |
421mm |
|
Bolt Circle Dia. |
440mm |
|
Gasket Thickness |
16mm |
|
Overall Depth |
197mm |
|
Net Weight |
11kg |
