Nominal Diameter |
18inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.3ohm |
|
Nominal Power Handling |
2000Watts |
|
Continuous Power Handling |
4000Watts |
|
Sensitivity |
98dB |
|
Frequency Range |
35-2KHz |
|
Voice-coil Diameter |
127.1mm |
|
Voice-coil Material |
Copper |
|
Chassis Material |
Aluminum |
|
Magnet Diameter |
280*25mm |
|
Magnet Material |
Ferrite |
|
Resonance Frequency |
Fs |
39Hz |
|
DC Resistance |
Rte |
5.3ohm |
|
Mechanical Factor |
Qms |
9.16 |
|
Electrical Factor |
Qes |
0.37 |
|
Total Factor |
Qts |
0.35 |
|
BL Factor |
BL |
27.8T-m |
|
Effective Moving Mass |
Mms |
216gr |
|
Equivalent Cas Air Load |
Vas |
141liter |
|
Effective Piston Area |
Sd |
0.116m |
|
Max. Linear Excursion |
Xmax |
10.1mm |
|
Vibration velocity |
Cms |
0.07 |
|
Overall Diameter |
472mm |
|
Baffle Cut-out Dia. |
415mm |
|
Bolt Circle Dia. |
452mm |
|
Gasket Thickness |
19mm |
|
Overall Depth |
210mm |
|
Net Weight |
21.9kg |
