GENERAL SPECIFICATIONS
|
Nominal Diameter |
12inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.1ohm |
|
Nominal Power Handling |
500Watts |
|
Continuous Power Handling |
1000Watts |
|
Sensitivity |
99dB |
|
Frequency Range |
50-3KHz |
|
Minimum Impedance |
5.1ohm |
|
Voice-coil Diameter |
75mm |
|
Voice-coil Material |
ALW |
|
Kind of layer |
In/out |
|
Magnet Diameter |
200*30mm |
|
Magnet Material |
Ferrite |
THIELE-SMALL PARAMETERS
|
Resonance Frequency |
Fs |
51Hz |
|
DC Resistance |
Rte |
5.1ohm |
|
Mechanical Factor |
Qms |
7.04 |
|
Electrical Factor |
Qes |
0.27 |
|
Total Factor |
Qts |
0.26 |
|
BL Factor |
BL |
18 T-m |
|
Effective Moving Mass |
Mms |
52 gr |
|
Equivalent Cas Air Load |
Vas |
79.25liter |
|
Effective Piston Area |
Sd |
0.055 m |
MOUNTING & SHIPPING INFORMATION
|
Overall Diameter |
315mm |
|
Baffle Cut-out Dia. |
283mm |
|
Bolt Circle Dia. |
297mm |
|
Gasket Thickness |
11mm |
|
Overall Depth |
138mm |
|
Net Weight |
8.45kg |
