GENERAL SPECIFICATIONS
|
Nominal Diameter |
15inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.4ohm |
|
Nominal Power Handling |
500Watts |
|
Continuous Power Handling |
1000Watts |
|
Sensitivity |
98.0db |
|
Frequency Range |
46-3.0KHZ |
|
Effective Diaphragm diameter |
338mm |
|
Voice-coil Diameter |
99.3mm |
|
Voice-coil Material |
CCAW |
|
Voice-coil Winding Depth |
22mm |
|
Number of layers |
2 |
|
Kind of layer |
in/out |
|
Magnet Diameter |
200*20mm |
|
Top Plate Thickness |
10 |
THIELE-SMALL PARAMETERS
|
Resonance Frequency |
Fs |
46Hz |
|
DC Resistance |
Rte |
5.4 ohm |
|
Mechanical Factor |
Qms |
5.94 |
|
Electrical Factor |
Qes |
0.30 |
|
Total Factor |
Qts |
0.29 |
|
BL Factor |
BL |
23.91 T-m |
|
Effective Moving Mass |
Mms |
109.2 gr |
|
Equivalent Cas Air Load |
Vas |
118.1 liters |
|
Effective Piston Area |
Sd. |
0.897 m2 |
|
Max. Linear Excursion |
Xmax |
7.5mm |
|
Half-Space Efficiency |
Eff |
3.55% |
MOUNTING INFORMATION
|
Overall Diameter |
388mm |
|
Mount Buffer Cut-out Diameter |
360mm |
|
Bolt Circle Diameter |
373mm |
|
Bolt Hole Diameter |
7.0mm |
|
Overall Depth |
130mm |
|
Not Weight |
9.3kg |
