GENERAL SPECIFICATIONS
|
Nominal Diameter |
10inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
4.5ohm |
|
Nominal Power Handling |
200Watts |
|
Continuous Power Handling |
400Watts |
|
Sensitivity |
96.0db |
|
Frequency Range |
45-3.0 KHZ |
|
Effective Diaphragm diameter |
220mm |
|
Voice-coil Diameter |
65.5mm |
|
Voice-coil Material |
CU |
|
Voice-coil Winding Depth |
16.5mm |
|
Number of layers |
2 |
|
Kind of layer |
Out |
|
Magnet Diameter |
170*20mm |
|
Top Plate Thickness |
8 |
THIELE-SMALL PARAMETERS
|
Resonance Frequency |
Fs |
45Hz |
|
DC Resistance |
Rte |
4.5 ohm |
|
Mechanical Factor |
Qms |
9.51 |
|
Electrical Factor |
Qes |
0.25 |
|
Total Factor |
Qts |
0.24 |
|
BL Factor |
BL |
15.58 T-m |
|
Effective Moving Mass |
Mms |
46.7 gr |
|
Equivalent Cas Air Load |
Vas |
51.06 liters |
|
Effective Piston Area |
Sd. |
0.380 m2 |
|
Max. Linear Excursion |
Xmax |
3.75mm |
|
Half-Space Efficiency |
Eff |
1.95% |
MOUNTING INFORMATION
|
Overall Diameter |
260 mm |
|
Mount Buffer Cut-out Diameter |
230 mm |
|
Bolt Circle Diameter |
246 mm |
|
Bolt Hole Diameter |
6.5 mm |
|
Overall Depth |
123 mm |
|
Net Weight |
4.6kg |
