GENERAL SPECIFICATIONS
|
Nominal Diameter |
18inch |
|
Nominal Impedance |
8ohm |
|
Minimum Impedance |
5.1ohm |
|
Nominal Power Handling |
1500Watts |
|
Continuous Power Handling |
3000Watts |
|
Sensitivity |
96.0db |
|
Frequency Range |
35-1.0KHZ |
|
Effective Diaphragm diameter |
390mm |
|
Voice-coil Diameter |
99.3mm |
|
Voice-coil Material |
Copper |
|
Voice-coil Winding Depth |
32.5mm |
|
Number of layer |
2 |
|
Kind of layer |
in/out |
|
Magnet Diameter |
220*30mm |
|
Top Plate Thickness |
15 |
THIELE-SMALL PARAMETERS
|
Resonance Frequency |
Fs |
35Hz |
|
DC Resistance |
Rte |
5.1ohm |
|
Mechanical Factor |
Qms |
12.23 |
|
Electrical Factor |
Qes |
0.495 |
|
Total Factor |
Qts |
0.476 |
|
BL Factor |
BL |
23.87 T-m |
|
Effective Moving Mass |
Mms |
246.8 gr |
|
Equivalent Cas Air Load |
Vas |
152 liters |
|
Effective Piston Area |
Sd. |
1.22 m2 |
|
Max. Linear Excursion |
Xmax |
12.5mm |
|
Half-Space Efficiency |
Eff |
1.6%
|
MOUNTING INFORMATION
|
Overall Diameter |
460mm |
|
Mount Buffer Cut-out Diameter |
424mm |
|
Bolt Circle Diameter |
445mm |
|
Bolt Hole Diameter |
7.0mm |
|
Overall Depth |
239mm |
|
Not Weight |
19.7kg |
